Xcel Arc Razor Multi 230 AC/DC Mig/Tig/Stick Welder
The RAZORWELD MULTI 230 AC/DC 4-in-1 welder. This machine can do any kind of welding you need it to. MIG, High-Frequency AC & DC TIG, as well as STICK, no matter what you’ve got planned, the RAZOR MULTI 230 AC/DC can do it.
- Innovative User Interface
- Full Weld Cycle HF AC/DC TIG Functionality
- Single Phase – 10 or 15 Amp Power supply Selectable (15A Plug)
- Spool Gun Ready
- Package Complete (as pictured)
- 3 Year Warranty
Package includes: Razor MIG230 ACDC Multi Powersource, 3m M22 Mig Torch, 4m ARC T3-FX Tig Torch, 4m Arc Lead Twist-Lock Electrode Holder, 4m Earth Lead, Argon Regulator, Input Lead & 15Amp Power Plug.
Have a question about this product?
Give us a call on 03 341 5591, or send us a email at [email protected]
TRUE 4 IN 1 MULTI PROCESS
MIG, AC/DC TIG, MMA
100+ SYNERGIC PROGRAMS
JUST SELECT YOUR METAL, WIRE SIZE, AND GAS, AND YOU’RE GOOD TO GO
5” LCD SCREEN
THE LARGE SCREEN DISPLAY IS CLEAR, WITH AN EASY TO NAVIGATE INTERFACE
GEARED WIRE DRIVE
Providing consistent and smooth wire feed
AC/DC High Frequency TIG
TIG weld aluminium without issues with AC. High-Frequency TIG (H/F TIG) gives you more control when starting or stopping the arc and reduces the risk of contaminating the tungsten or the weld.
PULSE MMA (STICK)
Pulse MMA (STICK) welding helps reduce spatter, improves heat control and allows for an easier removal of slag. It also improves the speed and efficiency of vertical up welds by eliminating the use of the “Christmas Tree” technique, while still maintaining root fusion.
Power Factor Correction (PFC)
PFC gives you maximum electrical efficiency and automatically compensates for any voltage fluctuation.
MIG Smart-Set
Setting up for a weld has never been easier, just set your wire, gas, joint type and material thickness and you’re ready to weld!
Complete MIG Weld Cycle Control
Get complete control over your MIG welds with a full set of adjustable parameters. It comes with the standard settings such as pre- and post-gas flow, arc ignition speed, and burnback. Plus it also includes more advanced features, like Arc Start and Crater Fill, for full control over the beginning and end of your welds.
Geared Wire Drive
This machine features a geared roller drive unit, providing consistent and smooth wire feed, and it helps when using longer MIG torches.
TIG Smart-Set
The easiest way to set up for a TIG weld, simply set your filler material, joint type and material thickness and you’re good to go!
Mix AC/DC
Mixed AC/DC welding is the combination of TIG AC and TIG DC- in one weld. Mixed AC/DC gives you faster welding speeds, better penetration, a faster weld puddle on cold workpieces, and you can weld on thicker materials.
Additional information
| Brand | Xcel Arc |
|---|
