Magmaweld E309Mo-16 Electrode 1.75-2kg Packet
An electrode for welding austenitic stainless Cr-Ni steels or cast steels having an extra low carbon content as well as stainless or heat resisting chromium steels or cast steels. Suitable for welding stainless tanks, valves, pipes and linings in chemical and food industries. For operating temperatures of up to +350˚C, non-scaling up to +800˚C. Easy arc striking and restriking. Fine metal droplet transfer, good fusion of joint faces, finely rippled bead surface, easily removable slag.
- Soft Start and Restrike
- Stable Arc
- Minimal Spatter
- Easy to Control Weld Deposition
- Easy Slag Removal
- Fine Ripple Bead Appearance
- International Approvals
Available in Diameters: 2.5mm (1.75kg) & 3.2mm (2.0kg).
Have a question about this product?
Give us a call on 03 341 5591, or send us a email at [email protected]
An electrode for welding austenitic stainless Cr-Ni steels or cast steels having an extra low carbon content as well as stainless or heat resisting chromium steels or cast steels. Suitable for welding stainless tanks, valves, pipes and linings in chemical and food industries. For operating temperatures of up to +350˚C, non-scaling up to +800˚C. Easy arc striking and restriking. Fine metal droplet transfer, good fusion of joint faces, finely rippled bead surface, easily removable slag.
- Soft Start and Restrike
- Stable Arc
- Minimal Spatter
- Easy to Control Weld Deposition
- Easy Slag Removal
- Fine Ripple Bead Appearance
- International Approvals
Standards, Classifications: AWS/ASME SFA 5.4 E309Mo-16 | AS/NZ 4854 | DIN 8556 E19 9 LR 26 | TS 2716 E 23 13 2 MPR 160 36
Typical Weld metal Analysis: C 0.065% Si 0.8% Mn 1.45% Cr 22% Ni 16% Mo 2.05%
Typical Mechanical Properties of Weld metal: Tensile Strength Elongation Impact Values 600N/mm² 35% 50(J)+20°C
